Screw Compressor C...R up to 7.5 kW

The flexible comprehensive solution

    • CONFIDENTLY CONTROLLED
      The base control unit with LC display and pressure sensor system is included as standard. However, the focus control 2.0 unit is also available as an option, with its integrated efficiency indicator, well-proven BOGE leakage monitor and RFID input.
    • PERFECTLY INTEGRATED
      The C series compressors are intelligently designed, with all of the essential components integrated in the compact module. The lack of hoses and connection pipes makes it practically impossible for leaks to occur.
    • HIGHLY EFFICIENT
      High air delivery rates achieved with particularly low power input – this is the trademark of the special BOGE airend of the C series compressors. The top efficiency ratings are also partly due to the intelligent arrangement of the components.
    • EFFECTIVELY UNITED
      Where space is at a premium: the C(D)R series combines a dryer and tank on a remarkably small floor area and runs with gratifying quietness – which means it can be used directly at the workplace.
    • img
    BOGE C 4 R

    Wherever space plays a role, the BOGE C...R series comes into its own, because its small footprint allows it to be installed at the workplace, right where it is needed. Each of the individual elements - from the receiver to the optional refrigerant dryer and oil/water seperator - come ready assembled and are delivered as a compact unit, ready for connection. In addition, the super selinced sound insulation ensures particularly quiet running. The pre-assembled pipework ensures tat both the installation work and space required are kept to an absolute minimum.

    Product

    Compact screw compressor mounted on a compressed air receiver, oil lubricated.

    Advantages

    • compact design
    • with receiver
    • extremely quiet
    • maximum efficiency
  • BOGE Max. Pressure Effective Delivery Volume
    50 Hz     		Motor Power Dimensions
    W × D × H    		 Weight
    Type bar psig m3/min cfm kW hp mm kg
    C 4 R 8 115 0.427 15.1 3 4 1880 x 927 x 1549 345
    C 4 R 10 150 0.340 12.0 3 4 1880 x 927 x 1549 345
    C 4 R 13 190 0.219 7.7 3 4 1880 x 927 x 1549 345
    C 5 R 8 115 0.601 21.2 4 5.5 1880 x 927 x 1549 350
    C 5 R 10 150 0.506 17.9 4 5.5 1880 x 927 x 1549 350
    C 5 R 13 190 0.386 13.6 4 5.5 1880 x 927 x 1549 350
    C 7 R 8 115 0.847 29.9 5.5 7.5 1880 x 927 x 1549 365
    C 7 R 10 150 0.736 26.0 5.5 7.5 1880 x 927 x 1549 365
    C 7 R 13 190 0.576 20.3 5.5 7.5 1880 x 927 x 1549 365
    C 9 R 8 115 1.180 41.7 7.5 10 1880 x 927 x 1549 370
    C 9 R 10 150 1.060 37.4 7.5 10 1880 x 927 x 1549 370
    C 9 R 13 190 0.870 30.7 7.5 10 1880 x 927 x 1549 370
