PERFECTION IN THE SMALLEST SPACE
Screw compressor C series (up to 22 kW)
Modular design
Extremely quiet
highest efficiency
Intelligent control: base control
Optional: focus control 2.0
Lubrication Type: Oil-lubricated
Cooling: Air- or water-cooled
Rated power: 2.2 - 22 kW
Effective delivery volume: Up to 3.620 m³/min
AT A GLANCE
The key technical advantages and flexible equipment options of the C-Series at a glance
The BOGE C-Series packs screw compressor technology into the smallest possible space: fewer pipes and connection points mean reduced flow losses, easier maintenance, and a modular design that can be configured into a turnkey, plug-and-play complete solution. With a performance range from 2.2 to 22 kW and the freedom to choose between belt drive and direct coupling, the C-Series meets virtually any requirement – uncompromisingly efficient and quiet.
Loading...
Discover the C Series
C Series: Efficiency that pays off
See what makes the C Series stand out: Discover the smart engineering behind a screw compressor designed for efficient operation, reliable performance and easy handling – a solution that delivers real value for your compressed air needs.
Loading...
Compressed air that adapts to your needs.
BOGE Screw Compressor C PM: Setting New Standards in Energy Efficiency and Reliability
While the C-series already offers a maximum level of efficiency and reliability, the C PM sets new standards once again in terms of energy savings, compactness, and ease of maintenance. With its innovative permanent magnet motor technology and wear-free construction, it defines the top class among industrial screw compressors.
TECHNICAL DATA & BIM PORTAL
All models and figures at a glance
Simply choose the correct construction variant for your selection. Whether delivery volume, rated power, operating pressure or dimensions, the following provides a concise overview of all relevant technical specifications for the series. Ideal for a quick comparison and planning. Depending on the product type, our BIM portal provides you with 2D and 3D drawings, documentation, operating manuals, spare parts lists and tailored maintenance offers.
Fad Max
[1]
[10]
Type | BIM | Operating Pressure (bar) | Effective delivery volume (min m³/min - max m³/min) | Motor Power (kW) | Receiver capacity (min liter - max liter) | Max dimensions (B x T x H mm) | Max weight (kg) |
|---|
DESIGN PRINCIPLES
Quality Features
The key technical advantages and flexible equipment options of the C-Series at a glance.
THE C LDR – WITH DRYER & RECEIVER
Everything covered: Configuration, maintenance, receiver size
The C-Series provides a suitable configuration for virtually every requirement: All individual elements are delivered fully pre-assembled as a plug-and-play compact unit – from stand-alone compressors to complete compressed air stations with receiver and refrigerant dryer. For easy maintenance, all components are arranged for easy access; sound-insulating panels can be removed in just a few simple steps, and open models do not even require the removal of an acoustic hood. The receiver size can be selected individually across all performance classes – up to 750 liters, and for models from 11 kW upward additionally with a galvanized finish for enhanced corrosion protection.
Holistic Compressed Air System Optimization
Integrated compressed air stations based on the C-Series can be combined with the BOGE treatment portfolio into a system that satisfies every purity and quality requirement: Highly efficient filters reliably separate particles as well as oil and water aerosols, external refrigerant dryers from the DS-2 family are suitable for higher compressed air demands, while heatless or heat-regenerated desiccant dryers achieve pressure dew points from -40 °C to -70 °C. For synthetic oils that can emulsify in condensate, multi-stage BOGE oil/water separators are available. Anyone wishing to expand the performance range to 11 to 22 kW will find the same advantages in the C-2 Series – including even more options for receivers, refrigerant dryers, and heat recovery.
CONTROL OPTIONS
Control & Digitalization
The C-Series offers the right level of control for every requirement: Even the standard base control with LC display and pressure sensor technology enables the compressor to operate autonomously as a complete compressed air station, including automatic frost protection and a leakage monitor. If you want to operate multiple compressors in a network, opt for the optional focus control 2.0, which coordinates up to four machines in base-load cycling and ensures redundancy. For larger, more complex compressed air systems, airtelligence provis 3 takes over the predictive, consumption-dependent control of an unlimited number of compressors and accessory components. And with BOGE connect, all plant data can be accessed at any time from any smart device – for early optimization and easier service.
)
TYPICAL AREAS OF APPLICATION
Versatile in use – always reliable.
This series includes integrated compressed air stations with tank and dryer and, in turn, deliver an extremely flexible system. Combined with our comprehensive range of high-quality treatment products, virtually any application can be optimally covered. However varied the requirements for the quality and purity of compressed air may be, these system components reliably meet the quality demands of the most disparate industries.
)
)
)
)
)
)
)
)
BOGE BESTCAIR, CAIRPAC AND MORE
Service & Warranty
BOGE bestcair: five years of peace of mind included. BOGE grants the five-year BOGE bestcair warranty on the BOGE C-Series. It covers all A-parts, registration for the warranty is free of charge, and in the event of a warranty claim, BOGE promptly provides replacement parts free of charge. Maintenance is carried out exclusively by certified BOGE service technicians using genuine BOGE parts. The corresponding BOGE cairpac maintenance packages bundle all parts required for maintenance – more cost-effective than purchasing components individually – and can be supplemented with tailored maintenance contracts ranging from plant inspection to full-service agreements.
Our Technical Support is on standby 24 hours a day, seven days a week. Certified BOGE service technicians are available worldwide for commissioning, maintenance, repair, and inspection.
